IDECHW4L-M0 Illuminated Pushbutton Operator 22mm Momentary Metal

Product Code: HW4L-M0

  • Locking lever removable contact blocks
  • Finger-safe IP20 contacts
  • Tamperproof construction
  • All E-stops meet EN60947-5-5, and are compliant with SEMI S2 standards
  • Worldwide approvals
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Product Type Pushbutton
Brand IDEC
Bezel Material Metal
Bezel Shape Round
Contact Material Silver
Cutout Size 22 mm
Degree of Protection IP65 Front, IP20 Terminal
Function Momentary
Illumination Illuminated
Insulation Resistance 100 MOhm
Mechanical Life 5 million Operations
Operational Temperature -25 to 60 deg C
Rated Frequency 50/60 Hz
Rated Insulation Voltage 600 V
Rated Thermal Current 10 A
Series HW
Standards and Approvals UL listed, CE marked, ULKA approved, CSA certified, TUV approved
Terminal Type Screw

Description

The IDEC HW4L-M0 is a robust 22mm metal operator designed for industrial applications. It features finger-safe (IP20) screw terminals and accepts ring connections for secure wiring. This unit is recognized for safety and quality with UL listing, CSA certification, TUV approval, and CE marking. It offers super bright incandescent or LED illumination options to ensure clear visibility in various operating conditions.

Documents

  • IPD Product Catalogue

    IPD Product Catalogue V17
