IDECHW2L-M1F01R-K Illuminated Pushbutton Kit 22mm Flush Momentary Red 1NC

Product Code: HW2L-M1F01R-K

  • Locking lever removable contact blocks
  • Finger-safe IP20 contacts
  • Tamperproof construction
  • All E-stops meet EN60947-5-5, and are compliant with SEMI S2 standards
  • Worldwide approvals
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Product Type Pushbutton Kit
Brand IDEC
Actuator Type Flush
Bezel Colour Black
Bezel Material Plastic
Bezel Shape Square
Contact Configuration 1NC
Contact Material Silver
Cutout Size 22 mm
Degree of Protection IP65 Front, IP20 Terminal
Diameter 22 mm
Function Momentary
Illumination Illuminated
Insulation Resistance 100 MOhm
Lamp Colour Red
Lamp Type Without Lamp
Mechanical Life 5 million Operations
Operational Temperature -25 to 60 deg C
Rated Frequency 50/60 Hz
Rated Insulation Voltage 600 V
Rated Thermal Current 10 A
Series HW
Standards and Approvals UL listed, CE marked, ULKA approved, CSA certified
Terminal Type Screw

Description

The IDEC HW2L-M1F01R-K is a high-quality illuminated pushbutton designed for momentary operation. This square flush red button features a durable plastic bezel and operates at full voltage. It includes 1 Normally Closed (NC) contact and is designed without a lamp. Ideal for various industrial applications, this pushbutton ensures reliable actuation and clear visual feedback for operators.
