IDECHW1LMF2F10QDG24V Illuminated Pushbutton 22mm Extended W/Shroud Momentary Green 24VAC/DC 1NO

Product Code: HW1LMF2F10QDG24V

  • Locking lever removable contact blocks
  • Finger-safe IP20 contacts
  • Tamperproof construction
  • All E-stops meet EN60947-5-5, and are compliant with SEMI S2 standards
  • Worldwide approvals
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Product Type Pushbutton
Brand IDEC
Actuator Type Extended with Shroud
Bezel Colour Black
Bezel Material Plastic
Bezel Shape Round
Contact Configuration 1NO
Contact Material Silver
Cutout Size 22 mm
Degree of Protection IP65 Front, IP20 Terminal
Diameter 22 mm
Function Momentary
Illumination Illuminated
Illumination Circuit Full Voltage
Insulation Resistance 100 MOhm
Lamp Colour Green
Lamp Type LED
Mechanical Life 5 million Operations
Operational Temperature -25 to 60 deg C
Rated Insulation Voltage 600 V
Rated Thermal Current 10 A
Rated Voltage 24 VAC/DC
Series HW
Standards and Approvals UL listed, CE marked, ULKA approved, CSA certified, TUV approved
Terminal Type Screw

Description

The IDEC HW1LMF2F10QDG24V is an illuminated 22mm pushbutton designed for safety and reliability. It features finger-safe (IP20) screw terminals that accommodate ring, fork, ferrule terminals, and bare wires. This pushbutton ensures compliance with EN418 for emergency stops, providing positive action as required by IEC standards. For added assurance, it is UL listed, CSA certified, TUV approved, and CE marked, signifying adherence to stringent safety regulations.
