IDECHW1L-M1F10QD-A24 Illuminated Pushbutton 22mm Flush Momentary Amber 24VAC/DC 1NO

Product Code: HW1L-M1F10QD-A24

  • Locking lever removable contact blocks
  • Finger-safe IP20 contacts
  • Tamperproof construction
  • All E-stops meet EN60947-5-5, and are compliant with SEMI S2 standards
  • Worldwide approvals
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Product Type Pushbutton
Brand IDEC
Actuator Type Flush
Bezel Colour Black
Bezel Material Plastic
Bezel Shape Round
Contact Configuration 1NO
Contact Material Silver
Cutout Size 22 mm
Degree of Protection IP65 Front, IP20 Terminal
Diameter 22 mm
Function Momentary
Illumination Illuminated
Illumination Circuit Full Voltage
Insulation Resistance 100 MOhm
Lamp Colour Amber
Lamp Type LED
Mechanical Life 5 million Operations
Operational Temperature -25 to 60 deg C
Rated Insulation Voltage 600 V
Rated Thermal Current 10 A
Rated Voltage 24 VAC/DC
Series HW
Standards and Approvals UL listed, CE marked, ULKA approved, CSA certified, TUV approved
Terminal Type Screw

Description

The IDEC HW1L-M1F10QD-A24 is a 22mm illuminated pushbutton featuring a 24V lamp for clear visibility. It comes with finger-safe (IP20) screw terminals that accommodate ring, fork, ferrule terminals, and bare wires for flexible installation options. The emergency stop functions are compliant with EN418 standards, ensuring positive action in critical situations. This pushbutton is recognized for its safety and quality with UL listing, CSA certification, TUV approval, and CE marking, making it suitable for a wide range of industrial applications.
