IDECHW1L-M122Q4G Illuminated Pushbutton 22mm Flush Momentary Green 2NO+2NC

Product Code: HW1L-M122Q4G

  • Locking lever removable contact blocks
  • Finger-safe IP20 contacts
  • Tamperproof construction
  • All E-stops meet EN60947-5-5, and are compliant with SEMI S2 standards
  • Worldwide approvals
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Product Type Pushbutton
Brand IDEC
Actuator Type Flush
Bezel Colour Black
Bezel Material Plastic
Bezel Shape Round
Contact Configuration 2NO+2NC
Contact Material Silver
Cutout Size 22 mm
Degree of Protection IP65 Front, IP20 Terminal
Diameter 22 mm
Function Momentary
Illumination Illuminated
Insulation Resistance 100 MOhm
Lamp Colour Green
Lamp Type Without Lamp
Mechanical Life 5 million Operations
Operational Temperature -25 to 60 deg C
Rated Insulation Voltage 600 V
Rated Thermal Current 10 A
Series HW
Standards and Approvals UL listed, CE marked, ULKA approved, CSA certified, TUV approved
Terminal Type Screw

Description

The IDEC HW1L-M122Q4G is an illuminated 22mm pushbutton designed for secure and versatile connections. It features finger-safe (IP20) screw terminals that accept ring, fork, ferrule terminals, and bare wires. This emergency stop pushbutton complies with EN418 standards for IEC-compliant positive action. For added reliability, it is UL listed, CSA certified, TUV approved, and CE marked, ensuring adherence to international safety regulations.
