IDECHW1L-A1F10QD-W24 Illuminated Pushbutton 22mm Flush Maintained White 24VAC/DC 1NO

Product Code: HW1L-A1F10QD-W24

  • Locking lever removable contact blocks
  • Finger-safe IP20 contacts
  • Tamperproof construction
  • All E-stops meet EN60947-5-5, and are compliant with SEMI S2 standards
  • Worldwide approvals
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Product Type Pushbutton
Brand IDEC
Actuator Type Flush
Bezel Colour Black
Bezel Material Plastic
Bezel Shape Round
Contact Configuration 1NO
Contact Material Silver
Cutout Size 22 mm
Degree of Protection IP65 Front, IP20 Terminal
Diameter 22 mm
Function Maintained
Illumination Illuminated
Illumination Circuit Full Voltage
Insulation Resistance 100 MOhm
Lamp Colour White
Lamp Type LED
Mechanical Life 5 million Operations
Operational Temperature -25 to 60 deg C
Rated Insulation Voltage 600 V
Rated Thermal Current 10 A
Rated Voltage 24 VAC/DC
Series HW
Standards and Approvals UL listed, CE marked, ULKA approved, CSA certified
Terminal Type Screw

Description

The IDEC HW1L-A1F10QD-W24 is a 22mm illuminated pushbutton featuring a flush operator and alternate action mechanism. It comes with a durable plastic bezel, ensuring longevity and resilience in various industrial environments. This white pushbutton is designed for clear visibility and easy operation, making it an ideal choice for control panels and interfaces where user interaction is required.
