IDECHW1L-A1F01QD-Y12 Illuminated Pushbutton 22mm Flush Maintained Yellow 12VAC/DC 1NC

Product Code: HW1L-A1F01QD-Y12

  • Locking lever removable contact blocks
  • Finger-safe IP20 contacts
  • Tamperproof construction
  • All E-stops meet EN60947-5-5, and are compliant with SEMI S2 standards
  • Worldwide approvals
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Product Type Pushbutton
Brand IDEC
Actuator Type Flush
Bezel Colour Black
Bezel Material Plastic
Bezel Shape Round
Contact Configuration 1NC
Contact Material Silver
Cutout Size 22 mm
Degree of Protection IP65 Front, IP20 Terminal
Diameter 22 mm
Function Maintained
Illumination Illuminated
Illumination Circuit Full Voltage
Insulation Resistance 100 MOhm
Lamp Colour Yellow
Lamp Type LED
Mechanical Life 5 million Operations
Operational Temperature -25 to 60 deg C
Rated Insulation Voltage 600 V
Rated Thermal Current 10 A
Rated Voltage 12 VAC/DC
Series HW
Standards and Approvals UL listed, CE marked, ULKA approved, CSA certified
Terminal Type Screw

Description

The IDEC HW1L-A1F01QD-Y12 is a 22mm illuminated pushbutton featuring a yellow flush operator for clear visibility and easy operation. Its alternate action functionality ensures reliable switching, while the durable plastic bezel offers a robust interface for industrial environments. Designed for use with a 12V system, this pushbutton integrates seamlessly into control panels and machinery interfaces.
