Hirschmann 942 328-006 Ethernet Switch 48VDC PoE 54VDC PoE+

Product Code: 942 328-006

  • Managed power supply for reliable operations
  • Rated power of 195.2W ensures efficiency
  • Compatible with 48VDC and 54VDC systems
  • Compact DIN Rail mounting: 68mm wide
  • Operates in extreme temps: -40 to 60°C
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Industrial Ethernet Switch
Brand
Hirschmann
Series
LRS

Electrical

Input Voltage
48 VDC (PoE) / 54 VDC (PoE+)

Mechanical

Mounting
DIN rail

Dimensions & Physical Data

Depth
118mm
Height
135mm
Weight
0.72kg
Width
68mm

Environmental

Operating Temperature
-40°C to 60°C
IP Rating
IP30

Communication & Control

Connectors/Input/Output
7x FE TX, 3x FE/GE SFP, 1x FE/GE Combo, PoE on up to 8 ports
Total Ports
11
Traffic Management
Static Unicast/Multicast Address Entries, VLAN (802.1Q), Independent VLAN Learning, QoS / Port Prioritization (802.1D/p), TOS/DSCP Prioritization, CoS Queue Management, Queue-Shaping / Max. Queue Bandwidth, Jumbo Frames, IGMP Snooping/Querier (v1/v2/v3), Unknown Multicast Filtering, IGMP Group Filtering per Port, Flow Control (802.3X), Egress Interface Shaping, Ingress Storm Protection
Network Management
LLDP (802.1AB), LLDP-MED, Password change on first login, SSHv2, HTTP, HTTPS, Responsive GUI, SNMP v1/v2/v3, Traps, Telnet, TFTP, Dual Software Image Support

Safety, Standards & Compliance

Standards and Approvals
CE, FCC, EN 61131 cUL 61010-4
