Hirschmann 942 224-001 PoE/PoE+ Injector 8 110-150VDC 100-240VAC 280 W

Product Code: 942 224-001

  • Delivers 280W power for efficient operation
  • Supports 110-150VDC, 100-240VAC input
  • Compact design: 77mm W x 128mm H x 117mm D
  • Operates in -25 to 70°C temperature range
  • IP30 protection for secure indoor use
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
POE Injector
Brand
Hirschmann
Series
RPI

Electrical

Rated Power
280W
Rated Voltage (Ur)
110 -150V DC and 100-240V AC

Mechanical

Port Configuration
8 x 10/100/1000 BASE-TX ports

Dimensions & Physical Data

Depth
117mm
Height
128mm
Weight
0.9kg
Width
77mm

Environmental

Operating Temperature without Derating
-25°C to 60°C
Operating Temperature
-25°C to 60°C
IP Rating
IP20

Safety, Standards & Compliance

Standards and Approvals
EN 60950-1, EN 61131-2, cUL60950-1 (pending) EN 50121-4

Documents

IPD Product Catalogue V17
