  • Hirschmann 942 170-007 Managed DIN Rail Mount Switch 4 x GIG SFP Fast Ethernet TX -Port 24VDC

Hirschmann 942 170-007 Managed DIN Rail Mount Switch 4 x GIG SFP Fast Ethernet TX -Port 24VDC

Product Code: 942 170-007

  • Managed switch with 4 GIG SFP ports
  • Rated power of 9W for efficient use
  • DIN rail mounting for easy installation
  • Operates in humidity from 1% to 95%
  • Complies with CE, FCC, EN standards
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Ethernet Switches
Brand
HIRSCHMANN
Series
BOBCAT

Electrical

Operating Voltage
2 x 12 VDC ... 24 VDC
Power Consumption
9 W
No. of Ports
12
Redundancy Protocols
MRP, RSTP, HSR, PRP, DLR

Mechanical

Cable Length (Supported Range)
0 – 100 m (Twisted Pair )
Cable Type
Twisted pair, Single mode fiber, Multimode fiber
Diagnostic Functions
LEDs, Link Flap Detection, Port Mirroring, RMON, Copper Cable Test
Housing
PC-ABS
Industrial Protocols
PROFINET, EtherNet/IP, Modbus TCP
Model
BRS30-8TX/4SFP
Mounting Type
DIN rail
Port Configuration
8 × Copper (RJ45) + 4 × Fiber port
VLAN Support
Yes (802.1Q, Voice VLAN, GVRP)

Dimensions & Physical Data

Depth
115 mm
Height
138 mm
Weight
570 g
Width
73 mm

Environmental

Storage Temperature
-40 - +70 °C
Operating Temperature
0 - +60 °C
IP Rating
IP30

Safety, Standards & Compliance

Standards and Approvals
CE, FCC, EN61131, EN62368-1
Security Features
ACL, DoS Prevention, 802.1X, Secure Boot, RADIUS

Documents

IPD Product Catalogue V17
