Connectors/Input/Output
TP-cable, auto-crossing, auto-negotiation, auto-polarity. Uplink ports 10/100/1000BASE-TX, M12 "X"-coded, 8-pins ; Local ports 10/100BASE-TX M12 "D"-coded, 4-pin
|
|
Traffic Management
CoS Queue Management, Egress Interface Shaping, Fast Aging, Flow Control (802.3X), Forward unknown multicast to query ports, IGMP Snooping/Querier per VLAN (v1/v2/v3), Independent VLAN Learning, Ingress Storm Protection, Interface Trust Mode, Jumbo Frames, Multiple MAC Registration Protocol (MMRP), Multiple Registration Protocol (MRP), Multiple VLAN Registration Protocol (MVRP), QoS / Port Prioritization (802.1D/p), Queue-Shaping / Max. Queue Bandwidth, Static Unicast/Multicast Address Entries, TOS/DSCP Prioritization, Unknown Multicast Filtering, VLAN (802.1Q), VLAN Unaware Mode, Voice VLAN
|
Network Management
Dual Software Image Support, HTTP, HTTPS, LLDP-MED, SFTP. SCP. LLDP (802.1AB), SNMP v1/v2/v3, SNMPv3 Traps, SSHv2, Telnet, TFTP, Traps, V.24, IPv6 Management
|
|
|
