  • Hirschmann 942 132-002 Unmanaged DIN Rail Mount Switch 8 x 10/100 Base-TX RJ45 -Port 12-24VDC

Hirschmann 942 132-002 Unmanaged DIN Rail Mount Switch 8 x 10/100 Base-TX RJ45 -Port 12-24VDC

Product Code: 942 132-002

  • Compact size: 38mm width, 102mm height, 79mm depth
  • Versatile mounting on DIN rail or wall
  • Operates in temperatures from 0 to 60°C
  • IP30 protection for indoor use
  • Supports 8 RJ-45 ports at 10/100 Base-TX
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Ethernet Switches
Brand
HIRSCHMANN
Series
SPIDER III

Electrical

Operating Voltage
12/24 V DC (9.6 - 32 V DC)
Power Consumption
1.5 W
No. of Ports
8

Mechanical

Cable Length (Supported Range)
0 – 100 m (Twisted Pair )
Cable Type
Twisted Pair
Diagnostic Functions
LEDs (power, link status, data, data rate)
Model
SSL20-8TX
Mounting Type
DIN rail
Port Configuration
8 × Copper (RJ45)

Dimensions & Physical Data

Depth
79 mm
Height
102 mm
Weight
150 g
Width
38 mm

Environmental

Storage Temperature
-40 - +70 °C
Operating Temperature
0 - +60 °C
IP Rating
IP30

Safety, Standards & Compliance

Standards and Approvals
CE, FCC, EN61131
