Hirschmann 942 132-001 Unmanaged DIN Rail Mount Switch 5 x 10/100 Base-TX -Port 32VDC

Product Code: 942 132-001

  • Unmanaged switch with 5 x 10/100 Base-TX ports
  • Compact design for DIN Rail or wall mounting
  • Low power consumption at 1.3 W
  • IP30 protection for indoor environments
  • Operates in temperatures from 0 to 50°C
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Ethernet Switches
Brand
HIRSCHMANN
Series
SPIDER III

Electrical

Operating Voltage
12/24 V DC (9.6 - 32 V DC)
Power Consumption
1.3 W
No. of Ports
5

Mechanical

Cable Length (Supported Range)
0 – 100 m (Twisted Pair )
Cable Type
Twisted Pair
Diagnostic Functions
LEDs (power, link status, data, data rate)
Model
SSL20-5TX
Mounting Type
DIN rail
Port Configuration
5 × Copper (RJ45)

Dimensions & Physical Data

Depth
79 mm
Height
102 mm
Weight
120 g
Width
26 mm

Environmental

Storage Temperature
-40 - +70 °C
Operating Temperature
0 - +60 °C
IP Rating
IP30

Safety, Standards & Compliance

Standards and Approvals
CE, FCC, EN61131
