Hirschmann 942 098-001 SFP Fast Ethernet Transceiver

Product Code: 942 098-001

  • Compact 14 mm width design
  • Fits into SFP slots for easy installation
  • RJ-45 connection for reliable connectivity
  • Operates in temperatures from 0 to 60°C
  • IP20 protection against solid objects
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Sfp Tx Fast Ethernet Transceiver
Brand
Hirschmann
Series
M-FAST SFP (Fast Ethernet SFP Transceiver)

Electrical

Operating Voltage
power supply via the switch
Power Consumption
1W
No. of Ports
1
Power Supply
power supply via the switch
Interface Type
SFP / RJ45-socket
Network Cable Type
Twisted pair (TP)

Mechanical

Cable Type
Twisted pair (TP)
Diagnostic Functions
Optical input and output power, transceiver temperature
Model
M-FAST SFP-TX/RJ45
Mounting
SFP slot
Port Configuration
100 Mbit/s RJ45-socket

Dimensions & Physical Data

Depth
70mm
Height
14mm
Weight
0.045kg
Width
14mm
Cable Length
0m to 100m
Network Cable Length
0-100 m

Environmental

Storage Temperature
-40°C to 85°C
Operating Temperature
0°C to 60°C
IP Rating
IP20

Communication & Control

Total Ports
1

Safety, Standards & Compliance

Standards and Approvals
Safety of IT equipment: EN 60950; EMC: EN 55022 Class A, FCC 47CFR Part 15, Class A; Hazardous locations: depending on deployed switch; Shipbuilding: depending on deployed switch
