Hirschmann 942 058-999-011 Industrial firewall and security router EtherNet (4xFE + 2xGE)

Product Code: 942 058-999-011

  • Supports 4 FE + 2 GE Ethernet connections
  • Wide voltage range: 110-230 VAC
  • Operates in -40 to 70°C environments
  • DIN Rail mountable for easy installation
  • IP20 protection rating
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Firewall
Brand
Hirschmann
Series
EAGLE30

Electrical

Connectors
6 ports in total; Ethernet Ports: 2 x SFP slots (100/1000 Mbit/s); 4 x 10/100BASE TX / RJ45
Rated Power
14W

Mechanical

Mounting
DIN Rail
Port Configuration
6 ports in total; Ethernet Ports: 2 x SFP slots (100/1000 Mbit/s); 4 x 10/100BASE TX / RJ45

Dimensions & Physical Data

Depth
120mm
Height
164mm
Weight
1.5kg
Width
98mm

Environmental

Storage Temperature
-40°C to 85°C
Operating Temperature
-40°C to 75°C
IP Rating
IP20

Communication & Control

USB Port
1 x USB to connect auto-configuration adapter ACA22-USB

Safety, Standards & Compliance

Standards and Approvals
CE; FCC; EN 61131; EN 60950 IEC 61850-3; IEEE 1613
