Emerson IC755CSW07CDA HMI Screen 6 in 29VDC 1 Ethernet Port 1 Serial Port

Product Code: IC755CSW07CDA

  • 6" touch screen display for easy interaction
  • Operates on Windows Embedded Compact 7 OS
  • IP65 rating ensures dust and water resistance
  • Equipped with Freescale i.Mx535 processor
  • DDR3 SDRAM 1 GB for efficient performance
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
HMI
Brand
Emerson
Series
QuickPanel+

Electrical

Power Consumption
15 W
Supply Voltage
24 V DC
Sunlight Readable
Yes
Touch Type
Resistive Touch
Memory Capacity
512 MB DDR2 SDRAM
Processor Type
MX535 1GHz based on ARM Cortex A13
Operating System
Microsoft® Windows® Embedded Compact 12
Hard Drive Capacity
256MB SLC NAND Flash 512KB Battery Backed SRAM

Dimensions & Physical Data

Depth
65 mm
Height
137 mm
Width
192 mm
Panel Cut-Out Size
183.5(W) x 128.5(H) mm
Display Size
6 inch

Environmental

Storage Temperature
-10°C to +60°C
Operating Temperature
0°C to +55°C
IP Rating
IP65F

Communication & Control

Ethernet Port Speed
10 Mbps/100 Mbps
Ethernet Ports
1xx 10Base-T (IEEE 802.3i)/ 100Base-TX (IEEE 802.3u)
Serial Ports
1x RS-232C
USB Port
3

Safety, Standards & Compliance

Hazardous Location Ratings
Class 1 Division 2; Class 2 Division 2; Class 3 Division 1 & 2 UL TYPE 4X
