Emerson IC695MDL765 Discrete Output Module

Product Code: IC695MDL765

  • Suitable for panel and DIN rail mounting
  • Certified for Zone 2 hazardous areas
  • Supports copper, MM, and SM fibre
  • Meets multiple marine approvals (ABS, BV, DNV)
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Discrete Output Module
Brand
Emerson
Series
Rx3i

Electrical

Channel Isolation
Transformer
Digital Inputs
0
Digital Outputs
8
Output Ratings
Resistive 2A at 132Vdc 2A at 30 Vdc Inductive (Pilot Duty) 0.6A at 132Vdc Incandescent (Lamp) 0.75A at 132Vdc 0.75A at 30 Vdc
Analog Outputs
0
Output Type
Resistive/ Inductive/ Incandescent
Power Consumption
3.3 VDC: 0.502W 5 VDC: 2.7W
Supply Voltage
24V DC
Terminal Type
Screw Terminal
Analog Inputs
0

Mechanical

Housing Material
Plastic

Dimensions & Physical Data

Depth
140mm
Height
145mm
Width
34mm

Environmental

Storage Temperature
0°C to 60°C
Operating Temperature
-40°C to 60°C
IP Rating
IP20
Conformal Coated
No

Safety, Standards & Compliance

Hazardous Location Ratings
Zone 2 CE, ATEX C1D2 ABS, BV, DNV, GL, KRS, LR UL HAZLOC
Certifications / Approvals
UL

Accessories & Additional Information

Development Software
PAC Machine Edition
