Emerson IC695ALG708 Analog Output Module 10VDC

Product Code: IC695ALG708

  • Supports Modbus, Profinet, Profibus protocols
  • Rated for 10 VDC and 0.02 A current
  • Mounts on panel or DIN rail
  • Operates up to 60°C
  • IP20 protection rating
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Analog Output Module
Brand
Emerson
Series
Rx3i

Electrical

Analog Resolution
±10 Vdc: 15.9 bits, 0 to 10 Vdc: 14.9 bits, 0 to 20mA: 15.9 bits, 4 to 20mA: 15.6 bits
Channel Isolation
Isolated
No. of Analog Outputs
8 Ch
Output Ratings
Current: 0 to 20mA, 4 to 20mA Voltage: ± 10 Vdc, 0 to 10 Vdc
Analog Outputs
8 Ch
Output Type
Voltage/Current
Power Consumption
1.238W
Supply Voltage
3.3V DC 24V DC
Terminal Type
Screw Terminal

Mechanical

Housing Material
Plastic

Dimensions & Physical Data

Depth
140mm
Height
145mm
Width
34mm

Environmental

Storage Temperature
0°C to 60°C
Operating Temperature
-40°C to 60°C
IP Rating
IP20

Safety, Standards & Compliance

Hazardous Location Ratings
Zone 2 CE, ATEX C1D2 ABS, BV, DNV, GL, KRS, LR UL HAZLOC
Certifications / Approvals
UL
