Emerson IC695ALG628 8-Channel Analog Input Module

Product Code: IC695ALG628

  • 8-channel input module for versatile use
  • Suitable for panel or DIN rail mounting
  • Zone 2 CE, ATEx C1D2 certified
  • Approved by ABS, BV, DNV, GL, KRS, LR
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Analog Input Module
Brand
Emerson
Series
Rx3i

Electrical

Channel Isolation
Opto and Transformer
No. of Analog Inputs
8 Single-ended 4 Differential
Input Ratings
Current: 0 to 20mA, 4 to 20mA, ±20mA Voltage: ±10 Vdc, 0 to 10 Vdc, ±5Vdc, 0 to 5Vdc, 1Vdc to 5Vdc
Input Type
Voltage/ Current
Power Consumption
2.25W
Supply Voltage
3.3V DC 5V DC
Terminal Type
Screw Terminal
Analog Inputs
8 Single-ended 4 Differential

Mechanical

Housing Material
Plastic

Dimensions & Physical Data

Depth
140mm
Height
145mm
Width
34mm

Environmental

Storage Temperature
0°C to 60°C
Operating Temperature
-40°C to 60°C
IP Rating
IP20

Safety, Standards & Compliance

Hazardous Location Ratings
Zone 2 CE, ATEX C1D2 ABS, BV, DNV, GL, KRS, LR UL HAZLOC
Certifications / Approvals
UL
