Specifications

Product Type

Analog Input Module

Brand

Emerson

Series

Rx3i

Channel Isolation Isolated	No. of Analog Inputs 8	Input Ratings RTD Inputs: 50, 100, 200, 500, and 1000 ohms Pt 385 50, 100, 200, 500, and 1000 ohms Pt 391.6 100, 200, 500, and 1000 ohms Ni 618 120 ohms Ni 672 604 ohms NiFe 518 10, 50 and 100 ohms Cu 426 Resistance Inputs: 250, 500, 1000, 2000, 3000, and 4000 ohms
Input Type Resistance/ RTD	Power Consumption 1W	Supply Voltage 3.3V DC 5V DC
Terminal Type Screw Terminal	Analog Inputs 8

Housing Material

Plastic

Depth

140mm

Height

145mm

Width

34mm

Storage Temperature

0°C to 60°C

Operating Temperature

-40°C to 60°C

IP Rating

IP20

Hazardous Location Ratings

Zone 2 CE, ATEX C1D2 ABS, BV, DNV, GL, KRS, LR UL HAZLOC

Certifications / Approvals

Emerson IC695ALG508 Analog Input Module 10VDC 8 Digital Outputs
