Emerson IC694MDL940 Discrete Output Module 125VDC 16 Digital Outputs

Product Code: IC694MDL940

  • Supports Modbus, Profinet, Profibus protocols
  • Rated for 125 VDC and 2 A current
  • Panel or DIN Rail mounting options
  • Operates up to 60°C with IP20 protection
  • Certified ATEx and IECEx standards compliant
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Discrete Output Module
Brand
Emerson
Series
Rx3i

Electrical

Channel Isolation
Optical Coupler
Digital Outputs
16
No. of Digital Outputs
16
Output Ratings
24 V DC 120/240 V AC
Output Type
Voltage
Power Consumption
0.035W (Backplane) 3.24W (Relay)
Supply Voltage
24V DC 120/240V AC
Terminal Type
Screw Terminal

Mechanical

Housing Material
Plastic

Dimensions & Physical Data

Depth
140mm
Height
145mm
Width
34mm

Environmental

Storage Temperature
0°C to 60°C
Operating Temperature
-40°C to 60°C
IP Rating
IP20

Safety, Standards & Compliance

Hazardous Location Ratings
Zone 2 CE, ATEX C1D2 ABS, BV, DNV, GL, KRS, LR UL HAZLOC
Certifications / Approvals
UL
