Emerson IC694MDL758 Discrete Output Module

Product Code: IC694MDL758

  • Supports panel and DIN rail mounting
  • Certified for Zone 2 CE, ATEx C1D2
  • Includes 2 x RJ-45 and 2 x SFP ports
  • Approved by ABS, BV, DNV, GL, KRS, LR
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Discrete Output Module
Brand
Emerson
Series
Rx3i

Electrical

Channel Isolation
Optical Coupler
Digital Inputs
0
Digital Outputs
32
Output Ratings
12/24 VDC
Analog Outputs
0
Output Type
Voltage
Power Consumption
1.25W (Backplane) 1.584W (Power Supply)
Supply Voltage
5V DC (Backplane) 12-24V DC (Power Supply)
Terminal Type
Screw Terminal
Analog Inputs
0

Mechanical

Housing Material
Plastic

Dimensions & Physical Data

Depth
140mm
Height
145mm
Width
34mm

Environmental

Storage Temperature
0°C to 60°C
Operating Temperature
-40°C to 60°C
IP Rating
IP20
Conformal Coated
No

Safety, Standards & Compliance

Hazardous Location Ratings
Zone 2 CE, ATEX C1D2 ABS, BV, DNV, GL, KRS, LR UL HAZLOC
Certifications / Approvals
UL

Accessories & Additional Information

Development Software
PAC Machine Edition
