Emerson IC694MDL260 Discrete Input Module 132VAC 32 Digital Inputs

Product Code: IC694MDL260

  • Supports Modbus, Profinet, Profibus protocols
  • Rated for 132 VAC operation
  • Panel and DIN rail mounting options
  • Operates up to 60°C temperature
  • IP20 protection rating
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Discrete Input Module
Brand
Emerson
Series
Rx3i

Electrical

Channel Isolation
Optical Coupler
Digital Inputs
32
Digital Outputs
0
Analog Outputs
0
Input Ratings
120 V AC
Input Type
Voltage
Power Consumption
1.1W
Supply Voltage
5V DC
Terminal Type
Screw Terminal
Analog Inputs
0

Mechanical

Housing Material
Plastic

Dimensions & Physical Data

Depth
140mm
Height
145mm
Width
34mm

Environmental

Storage Temperature
0°C to 60°C
Operating Temperature
-40°C to 60°C
IP Rating
IP20
Conformal Coated
No

Safety, Standards & Compliance

Hazardous Location Ratings
Zone 2 CE, ATEX C1D2 ABS, BV, DNV, GL, KRS, LR UL HAZLOC
Certifications / Approvals
UL

Accessories & Additional Information

Development Software
PAC Machine Edition
