Emerson IC694MDL241 Discrete Input Module 30VAC 16 Digital Inputs

Product Code: IC694MDL241

  • Supports Modbus, Profinet, Profibus protocols
  • Operates at 30 VAC rated voltage
  • Mounts on panel or DIN rail
  • Suitable for up to 60°C operational temp
  • IP20 protection rating
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Discrete Input Module
Brand
Emerson
Series
Rx3i

Electrical

Channel Isolation
Optical Coupler
Digital Inputs
16
No. of Digital Inputs
16
Input Ratings
24 V AC/DC
Input Type
Voltage
Power Consumption
0.40W (Backplane) 3W (User Supplied)
Supply Voltage
24V DC (User Supplied) 5V DC (Backplane)
Terminal Type
Screw Terminal

Mechanical

Housing Material
Plastic

Dimensions & Physical Data

Depth
140mm
Height
145mm
Width
34mm

Environmental

Storage Temperature
0°C to 60°C
Operating Temperature
-40°C to 60°C
IP Rating
IP20

Safety, Standards & Compliance

Hazardous Location Ratings
Zone 2 CE, ATEX C1D2 ABS, BV, DNV, GL, KRS, LR UL HAZLOC
Certifications / Approvals
UL
