Emerson IC694APU300 Discrete Mixed Module 18 Digital Inputs 4 Digital Outputs

Product Code: IC694APU300

  • Supports Modbus, Profinet, Profibus protocols
  • Suitable for panel and DIN rail mounting
  • Operates up to 60°C efficiently
  • IP20 protection rating
  • Complies with ATEx and IECEx standards
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
High Speed Counter Module
Brand
Emerson
Series
Rx3i

Electrical

Channel Isolation
Galvanic Isolation
Digital Inputs
12
Digital Outputs
4
No. of Digital Inputs
12
No. of Digital Outputs
4
Output Ratings
10 VDC - 30 VDC (500 mA) 4.75 VDC - 6 VDC (20 mA)
Input Ratings
5 VDC (TSEL jumpered to INCOM) 10 VDC - 30 VDC (TSEL open)
Input Type
Positive Logic Single Ended
Output Type
Positive Logic Single Ended
Power Consumption
1.25W (Backplane)
Supply Voltage
5V DC
Terminal Type
Screw Terminal

Mechanical

Housing Material
Plastic

Dimensions & Physical Data

Depth
140mm
Height
145mm
Width
34mm

Environmental

Storage Temperature
0°C to 60°C
Operating Temperature
-40°C to 60°C
IP Rating
IP20

Safety, Standards & Compliance

Hazardous Location Ratings
Zone 2 CE, ATEX C1D2 ABS, BV, DNV, GL, KRS, LR UL HAZLOC
Certifications / Approvals
UL
