Emerson EP-5442 PACSystems™ RSTi-EP 2 Channels PWM Output, Positive Logic, 24VDC, 0.5 A

Product Code: EP-5442

  • Supports Profinet RT, Profibus, Modbus TCP & EtherCAT
  • 2 channels for versatile connectivity
  • Operates at 24 VDC with low current draw
  • DIN rail mounting for easy installation
  • IP20 protection rating
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Special Function Modules
Brand
Emerson
Series
RSTi-EP

Electrical

Digital Outputs
2 Ch
Output Ratings
4:00 AM
Output Type
PN output stage
Supply Voltage
20.4V – 28.8V
Terminal Type
Spring-Style

Dimensions & Physical Data

Depth
11.5 mm
Height
120 mm
Width
76 mm

Environmental

Storage Temperature
-40°C to +85°C
Operating Temperature
-20°C to +60°C
IP Rating
IP20

Safety, Standards & Compliance

Hazardous Location Ratings
UL HazLoc Class 1 Division 2 ATEX Zone 2
Safety Integrity Level
SIL3
Certifications / Approvals
UL,CE,FCC, CCC

Documents

IPD Product Catalogue V17
