Emerson EP-5311 PACSystems™ RSTi-EP SSI Encoder, BCD or Gray-Code Format, 5/24 VDC

Product Code: EP-5311

  • Supports Profinet RT, Profibus, Modbus TCP & EtherCAT
  • Low current consumption: 8 mA, 35 mA
  • PNSR redundancy for reliability
  • Easy DIN rail mounting
  • Operates in -20 to 60°C range
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Special Function Modules
Brand
Emerson
Series
RSTi-EP

Electrical

Digital Inputs
1 Ch
Digital Outputs
1 Ch
No. of Digital Inputs
1 Ch
No. of Digital Outputs
1 Ch
Output Ratings
5-11VDC 0.5A 24VDC
Input Type
SSI (Differential RS-422)
Output Type
SSI (Differential RS-422)
Supply Voltage
20.4V to 28.8V
Terminal Type
Spring-Style

Dimensions & Physical Data

Depth
11.5mm
Height
120mm
Width
76mm

Environmental

Storage Temperature
-40°C to 85°C
Operating Temperature
-20°C to 60°C
IP Rating
IP20

Safety, Standards & Compliance

Hazardous Location Ratings
UL HazLoc Class 1 Division 2 ATEX Zone 2
Safety Integrity Level
SIL3
Certifications / Approvals
UL, CE, FCC, CCC
