Emerson EP-5111 PACSystems™ RSTi-EP 1 Channel High Speed Counter, AB 100 kHz, 1 DO 24VDC, 0.5A

Product Code: EP-5111

  • Supports Profinet, Profibus, Modbus TCP & EtherCAT
  • Single channel for efficient operation
  • DIN rail mounting for easy installation
  • Operates in -20 to 60°C temperature range
  • IP20 protection rating
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Special Function Modules
Brand
Emerson
Series
RSTi-EP

Electrical

Channel Isolation
Galvanic
Digital Inputs
1 Ch
Digital Outputs
1 Ch
Output Ratings
5-11V Incremental encoders 0.5A 24VDC
Input Ratings
100 kHz
Input Type
Incremental encoders and other input characteristics for sensor types 1 and 3 are in accordance with EN 61131-2
Output Type
Current
Supply Voltage
20.4V to 28.8V
Terminal Type
Spring-Style

Dimensions & Physical Data

Depth
11.5mm
Height
120mm
Width
76mm

Environmental

Storage Temperature
-40°C to 85°C
Operating Temperature
-20°C to 60°C
IP Rating
IP20

Safety, Standards & Compliance

Hazardous Location Ratings
UL HazLoc Class 1 Division 2 ATEX Zone 2
Safety Integrity Level
SIL3
Certifications / Approvals
UL, CE, FCC, CCC
