Emerson EP-4264 PACSystems™ RSTi-EP Analog Outputs 4 Channels Voltage/Current 16 Bits with Diagnostics 2, 3, or 4 Wire

Product Code: EP-4264

  • Supports Profinet RT, Profibus, Modbus TCP & EtherCAT
  • 4 channels with rated current of 8 mA and 85 mA
  • PNSR redundancy for reliable performance
  • Easy DIN Rail mounting for convenience
  • Operates in temperatures from -20 to 60°C
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Analog Output Module
Brand
Emerson
Series
RSTi-EP

Electrical

No. of Analog Outputs
4
Output Ratings
Voltage (0 - 5 V, ±5 V, 0 - 10 V, ±10 V, 1 - 5 V, 2 - 10V) Current (0 - 20 mA, 4 - 20 mA)
Analog Outputs
4
Output Type
Voltage/Current
Supply Voltage
20.4V to 28.8V
Terminal Type
Spring-Style

Dimensions & Physical Data

Depth
11.5mm
Height
120mm
Width
76mm

Environmental

Storage Temperature
-40°C to 85°C
Operating Temperature
-20°C to 60°C
IP Rating
IP20

Safety, Standards & Compliance

Hazardous Location Ratings
UL HazLoc Class 1 Division 2 ATEX Zone 2
Safety Integrity Level
SIL3
Certifications / Approvals
UL, CE, CCC

Documents

IPD Product Catalogue V17
