Emerson EP-3164 PACSystems™ RSTi-EP Analog Inputs 4 Channels Voltage/Current 16 Bits 2, 3, or 4 Wire

Product Code: EP-3164

  • Supports Profinet RT, Profibus, Modbus TCP & EtherCAT
  • 4 input channels for versatile applications
  • Compact DIN Rail mounting design
  • Operates in -20 to 60°C temperature range
  • IP20 protection with ATEx and IECEx approvals
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Analog Input Module
Brand
Emerson
Series
RSTi-EP

Electrical

No. of Analog Inputs
4
Input Ratings
Voltage (0 - 5 V, ±5 V, 0 - 10 V, ±10 V, 1 - 5 V, 2 - 10V) Current (0 - 20 mA, 4 - 20 mA)
Input Type
Voltage/Current
Supply Voltage
20.4V to 28.8V
Terminal Type
Spring-Style
Analog Inputs
4

Dimensions & Physical Data

Depth
11.5mm
Height
120mm
Width
76mm

Environmental

Storage Temperature
-40°C to 85°C
Operating Temperature
-20°C to 60°C
IP Rating
IP20

Safety, Standards & Compliance

Hazardous Location Ratings
UL HazLoc Class 1 Division 2 ATEX Zone 2
Safety Integrity Level
SIL3
Certifications / Approvals
UL, CE, CCC

Documents

IPD Product Catalogue V17
