Emerson EP-2714 PACSystems™ RSTi-EP Digital Outputs 4 Points, Positive Logic, 24 - 220 VDC/VAC, 6A, 2 Wire

Product Code: EP-2714

  • Supports Profinet RT, Profibus, Modbus TCP & EtherCAT
  • Operates on 24-220 VDC/AC with 8 mA or 20 mA current
  • DIN Rail mounting for easy installation
  • IP20 protection and ATEx, IECEx approved
  • Compatible with PAC Systems RSTi-EP
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Digital Output Module
Brand
Emerson
Series
RSTi-EP

Electrical

Digital Outputs
4
Output Ratings
6A
Output Type
Current
Supply Voltage
20.4V to 28.8V
Terminal Type
Spring-Style

Dimensions & Physical Data

Depth
11.5mm
Height
120mm
Width
76mm

Environmental

Storage Temperature
-40°C to 85°C
Operating Temperature
-20°C to 60°C
IP Rating
IP20

Safety, Standards & Compliance

Hazardous Location Ratings
UL HazLoc Class 1 Division 2 ATEX Zone 2
Safety Integrity Level
SIL3
Certifications / Approvals
UL, CE, CCC
