Emerson 8920-PS-DC Intrinsically Safe Module DC Power Supply 12VDC

Product Code: 8920-PS-DC

  • 12 VDC rated voltage for reliable power.
  • Operates efficiently up to 70°C.
  • IP20 protection against solid objects.
  • Part of the robust PAC8000 series.
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Power Supply
Brand
Emerson
Series
PAC8000

Electrical

Channel Isolation
Galvanically isolated
Output Ratings
5A at 12 VDC
Input Ratings
18.5 to 36 V DC
Input Type
DC power input
Output Type
DC
Supply Voltage
24 VDC
Terminal Type
Screw Terminal

Mechanical

Mounting Method
DIN Rail

Dimensions & Physical Data

Depth
160 mm
Height
110 mm
Width
84 mm

Environmental

Storage Temperature
– 40°C to + 85°C
Operating Temperature
(60% of full load) : – 40°C to + 70°C Optimum orientation(full load) : – 40°C to + 55°C Worst case orientation : – 40°C to + 50°C
IP Rating
IP20

Safety, Standards & Compliance

Compliance Standards
EMC compliance: To EN 50081-2 and EN 50082-2, generic emission/immunity standards, EN 61000-3-2:1995 EN 61000-3-3:1995 Electrical safety: EN 61010-1:1993 and Amendment A2:1995 and EN 61131-2:1994
Hazardous Location Ratings
Class 1, Div 2, Group A, B, C, D hazardous location Zone 2, IIC T4 hazardous area

Documents

IPD Product Catalogue V17
