Product Code: 8206-TI-IS

Supports Modbus and Profinet protocols
Compact DIN Rail mounting
IP20 protection rating
ATEx and IECEx approved
Independent o/c failure detection

Specifications

General

Product Type

Analog Input Modules

Brand

Emerson

Series

PAC8000

Electrical

Analog Resolution 16 bits	Input Ratings RTDs: Pt100 (-200-850°C), jPt100(-200-650°C), Ni120(-60-250°C) Excitation Current: 211 uA (0 - 110 ohms, 0 - 280 ohms, 0 - 470 ohms)/ 48 uA (0 - 2000 ohms)	Input Type RTD/ Resistance
Power Consumption 1.5 W	Supply Voltage Railbus : 12 VDC	Analog Inputs 8 Ch

Mechanical

Mounting Method

DIN rail

Dimensions & Physical Data

Depth

140 mm

Height

145 mm

Width

34 mm

Environmental

Conformal Coating

Yes

Operating Temperature

-40 to 70 °C

IP Rating

IP20

Safety, Standards & Compliance

Compliance Standards

CSA

Hazardous Location Ratings

Class I Div 2, ATEX Zone 2

Accessories & Additional Information

Development Software

PAC Machine Edition

Emerson 8206-TI-IS 8-Channel Intrinsically Safe RTD Input 4 Digital Inputs

Product Code: 8206-TI-IS
