Emerson 8139-SH-DC 126-Channel Addressable Smoke And Heat

Product Code: 8139-SH-DC

  • Handles up to 126 channels efficiently
  • Compatible with PAC8000 Remote I/O
  • Operates in -40 to 70°C temperature range
  • IP20 protection rating for safe use
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Smoke And Heat Detector I/O Module
Brand
Emerson
Series
PAC8000

Electrical

Digital Inputs
126 Ch
Digital Outputs
126 Ch
Output Ratings
5-9 V
Input Ratings
5-9 V
Input Type
Voltage
Output Type
Voltage
Supply Voltage
Railbus : 12 VDC Bussed Field: 24 VDC
Terminal Type
Screw Terminal

Dimensions & Physical Data

Depth
106mm
Height
110mm
Width
42mm

Environmental

Operating Temperature
-40°C to 70°C
IP Rating
IP20
Conformal Coated
Yes

Safety, Standards & Compliance

Hazardous Location Ratings
Class 1, Div 2, Groups A, B, C, D T4 ATEX Zone 2 ISA Level G3 corrosive atmospheres
Safety Integrity Level
SIL 2
Certifications / Approvals
CSA

Documents

IPD Product Catalogue V17
