Delta PDB1211A230035 Bypass Switch 1000VA 200/208/220/230/240VAC

Product Code: PDB1211A230035

  • Supports 200-240 VAC, 50/60 Hz
  • Power capacity of 1000 VA
  • Six IEC C13 receptacles
  • Compact size: 270x88x75 mm
  • Operates in 0 to 40°C range
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Bypass box
Brand
Delta
Series
PDB
Application
Maintenance bypass for Delta R/RT 1kVA UPS

Electrical

1P / 3P / DC
1P
kVA / kW (at unity Power Factor)
1kVA
Maintenance Bypass
Manual maintenance bypass
Terminal Type
IEC C14 input / IEC C13 output

Mechanical

Tower / Rack / Cabinet
Wall mount

Dimensions & Physical Data

Depth
75 mm
Height
88 mm
Weight
1.1 kg
Width
270 mm

Environmental

Operating Temperature without Derating
0-40°C
IP Rating
IP20

Safety, Standards & Compliance

Standards and Approvals
IEC/EN 62040-1; IEC/EN 62040-2

Documents
