DEHN KKH25FS Ball Head Cap 42000A 25mm Fixed Ball Point 8mm W 3mm D 17mm H Copper Alloy

Product Code: KKH25FS

  • Supports cables 25 to 120 sq-mm
  • Copper alloy construction
  • Operates in -25 to 55°C range
  • Complies with EN/IEC 61230 standards
  • Rated for 42,000 A current
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Rigid Ball Head Cap With Wing Bolt
Brand
DEHN
Series
Earth Connecting Elements for Switchgear Installations and Overhead Lines
Application
Connection elements in accordance with EN / IEC 61230 (DIN VDE 0683-100) for single-pole / three-pole earthing and short-circuiting cables

Electrical

Max. Short Circuit Current
42kA
Fixed Ball Point Diameter
25mm

Mechanical

Cable Cross Section
16mm² to 150mm²
Material
Cu alloy/gal Sn, E-Cu/gal Sn, Hardened/nikel-plated steel, Spring steel

Dimensions & Physical Data

Weight
0.747kg
