DEHN KKH20FS Ball Head Cap 33500A 20mm Fixed Ball Point 9mm W 3mm D 11mm H Copper Alloy

Product Code: KKH20FS

  • Rated for 33500 A current capacity
  • Compatible with 25-120 sq-mm cables
  • Operates from -25 to 55°C
  • Made of durable copper alloy
  • Complies with EN/IEC 61230 standards
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Rigid Ball Head Cap With Wing Bolt
Brand
DEHN
Series
Earth Connecting Elements for Switchgear Installations and Overhead Lines
Application
Connection elements in accordance with EN / IEC 61230 (DIN VDE 0683-100) for single-pole / three-pole earthing and short-circuiting cables

Electrical

Max. Short Circuit Current
33.5kA
Fixed Ball Point Diameter
20mm

Mechanical

Cable Cross Section
16mm² to 120mm²
Material
Cu alloy/gal Sn, E-Cu/gal Sn, Hardened/nikel-plated steel, Spring steel

Dimensions & Physical Data

Weight
0.48kg
