DEHN DGSEDC900FM Surge Arrester 12.5kA 750V 35mm DIN Rail Mount Thermoplastic IP20

Product Code: DGSEDC900FM

  • Surge protection up to 750 V, 12.5 kA
  • Compact design: 27mm width, IP20 rated
  • Quick response time of <=25 ns
  • Easy DIN Rail mounting (35 mm)
  • Operates in -40 to 80°C range
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Surge Arrester
Brand
DEHN
Series
DEHNguard ME/SE DC (FM)
Application
For protecting d.c. consumer installations

Electrical

Max. Backup Fuse
80A gPV
Nominal Voltage
750V DC
Voltage Protection Level Up
3000V
Short Circuit Current Rating
25kA
Alarm Contact
Changeover contact
Nominal Discharge Current Inom (8/20µs)
12.5kA
No. of Poles
1P
Max. Continuous Operating Voltage
900 V DC

Mechanical

Terminal Size
1.5 to 35 mm2

Dimensions & Physical Data

No. of Modules Width
1.5

Environmental

Operating Temperature
-40°C to 80°C
IP Rating
IP20

Documents

IPD Product Catalogue V17
