DEHN DGSECIWE440FM Surge Arrester With Fuse 1-P 12.5kA 400V 35mm DIN Rail Thermoplastic IP20

Product Code: DGSECIWE440FM

  • Protects up to 400 V, 12.5 kA current
  • Quick response time of <= 25 ns
  • Compact design: 27mm wide, mounts on DIN Rail
  • Operates in extreme temps: -40 to 80°C
  • IP20 protection with thermoplastic build
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Surge Arrester
Brand
DEHN
Series
DEHNguard SE CI with integrated backup fuse
Application
For industrial applications with a rated voltage of 400 / 690 V

Electrical

Max. Backup Fuse
Not required
Nominal Voltage
400V AC
Voltage Protection Level Up
3000V
Short Circuit Current Rating
25kA
Alarm Contact
Changeover contact
Nominal Discharge Current Inom (8/20µs)
12.5kA
No. of Poles
1P
Max. Continuous Operating Voltage
440 V AC

Mechanical

Terminal Size
1.5 to 35 mm2

Dimensions & Physical Data

No. of Modules Width
1.5

Environmental

Operating Temperature
-40°C to 80°C
IP Rating
IP20

Documents

IPD Product Catalogue V17
