DEHN DGS150FM Surge Arrester With CO Guard 1-P 15kA 120V 35mm DIN Rail Thermoplastic IP20

Product Code: DGS150FM

  • Surge protection with 15 kA current rating
  • Compact design: 18 mm width, 90 mm height
  • Quick response time of <= 25 ns
  • IP20 protection, suitable for indoor use
  • Easy DIN rail mounting on 35 mm rails
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Surge Arrester
Brand
DEHN
Series
DEHNguard S
Application
For protecting low-voltage consumer's installations against surges

Electrical

Max. Backup Fuse
125A gG
Nominal Voltage
120V AC
Voltage Protection Level Up
700V
Max. Discharge Current Imax (8/20µs)
40kA
Short Circuit Current Rating
50kA
Alarm Contact
Changeover contact
Nominal Discharge Current Inom (8/20µs)
15kA
No. of Poles
1P
Max. Continuous Operating Voltage
150 V AC, 200 V DC

Mechanical

Terminal Size
1.5 to 35 mm2

Dimensions & Physical Data

No. of Modules Width
1

Environmental

Operating Temperature
-40°C to 80°C
IP Rating
IP20

Documents

IPD Product Catalogue V17
