DEHN DGMYPV1200FM Type-2 Surge Arrester 40kA 35mm DIN Rail Thermoplastic IP20

Product Code: DGMYPV1200FM

  • Surge protection for PV systems
  • Handles 40 kA current (L-N, N-PE)
  • Compact size: 54x90x66 mm
  • Quick response time: <= 25 ns
  • UL & KEMA approved
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Combined lightning current and surge arrester
Brand
DEHN
Series
DCB YPV
Application
PV systems

Electrical

Lightning Impulse Current Iimp (10/350µs)
6.25 kA
Voltage Protection Level Up
< 4.5 kV
Max. Discharge Current Imax (8/20µs)
40 kA
Short Circuit Current Rating
10 kA
Nominal Discharge Current Inom (8/20µs)
20 kA
Max. PV Voltage [DC+ -> DC-] (UCPV)
≤ 1500 V

Mechanical

Cross-Sectional Area
35 mm^2 stranded / 25 mm2 flexible
Material
thermoplastic
Mounting Method
35 mm DIN rails

Dimensions & Physical Data

Depth
90mm
Height
73mm
Weight
562 g
Width
72mm

Environmental

Operating Temperature
-40 °C ... +80 °C
IP Rating
IP 20
