DEHN DGMWE600 M-Surge Arrester 15kA 480V 35mm DIN Rail Mount Thermoplastic IP20

Product Code: DGMWE600

  • Protects up to 480 V with 15 kA current rating
  • Compact design for 35 mm DIN rail mounting
  • Fast response time of <= 25 ns
  • Operates in -40 to 80°C temperature range
  • Complies with KEMA and UL standards
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Surge Arrester
Brand
DEHN
Series
DEHNguard modular
Application
For protecting low-voltage consumer's installations against surges

Electrical

Max. Backup Fuse
100A gG
Nominal Voltage
480V AC
Voltage Protection Level Up
3000V
Max. Discharge Current Imax (8/20µs)
25kA
Short Circuit Current Rating
25kA
Nominal Discharge Current Inom (8/20µs)
15kA
No. of Poles
3P
Max. Continuous Operating Voltage
600 V AC

Mechanical

Terminal Size
1.5 to 35 mm2

Dimensions & Physical Data

No. of Modules Width
3

Environmental

Operating Temperature
-40°C to 80°C
IP Rating
IP20

Documents

IPD Product Catalogue V17
