DEHN DCORL1P320 Surge Arrester 1-P 5kA 230/277VAC Thermoplastic Red IP20

Product Code: DCORL1P320

  • Surge protection for 230/277 VAC systems
  • Compact design: 49mm width, 50mm height
  • Fast response time: <= 25 ns (L-N)
  • Durable thermoplastic construction
  • Rated short circuit current: 25 kA
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Surge Arrester
Brand
DEHN
Series
DEHNcord
Application
For protecting low-voltage consumer installations against surges

Electrical

Max. Backup Fuse
25A gG
Nominal Voltage
230V AC, 277V AC
Voltage Protection Level Up
1750V
Max. Discharge Current Imax (8/20µs)
10kA
Short Circuit Current Rating
25kA
Nominal Discharge Current Inom (8/20µs)
5kA
No. of Poles
1P
Max. Continuous Operating Voltage
320 V AC

Environmental

Operating Temperature
-40°C to 80°C
IP Rating
IP20
