DEHN BXTML4BE36 Lightning Current Arrester 10kA 1.8A 36V 3.8MHz 12mm W 51mm D 45mm H Polyamide Yellow IP20

Product Code: BXTML4BE36

  • Surge protection device with Type 1 SPD
  • Rated voltage of 36 V, current of 1.8 A
  • Compact size: 12 mm W x 45 mm H x 51 mm D
  • Operates in extreme temps: -40 to 80°C
  • Complies with IEC, UL, ATEX standards
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Combined Lightning Current And Surge Arrester Module
Brand
DEHN
Series
BLITZDUCTOR XT
Application
For protecting four single lines sharing a common reference potential as well as unbalanced interfaces

Electrical

Lightning Impulse Current Iimp (10/350µs)
10kA
No. of Lines/Pairs
4 single lines
Nominal Current (In)
1.8 A
Nominal Voltage
36V
Voltage Protection Level Up
112V
Nominal Discharge Current Inom (8/20µs)
20kA
Max. Continuous Operating Voltage
31 V AC / 45 V DC

Environmental

Operating Temperature
-40°C to 80°C
IP Rating
IP20

Documents

IPD Product Catalogue V17
