DEHN BXTML4BE24 Lightning Current Arrester 10kA 0.75A 24V 6.8MHz 12mm W 51mm D 45mm H Polyamide Yellow IP20

Product Code: BXTML4BE24

  • Signal line protector with 24V rating
  • Compact size: 12mm width, 45mm height
  • Operates in -40 to 80°C temperature range
  • Complies with IEC, UL, ATEX standards
  • Lightning impulse current of 10 kA
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Combined Lightning Current And Surge Arrester
Brand
DEHN
Series
BXT ML4 BE
Application
Protection of four single lines

Electrical

Lightning Impulse Current Iimp (10/350µs)
2.5kA per line / 10kA total
Nominal Current (In)
0.75 A
Nominal Voltage
24V
Voltage Protection Level Up
≤ 102V (LL), ≤ 66V (L-PG), ≤ 90V / ≤ 45V (C3)
Nominal Discharge Current Inom (8/20µs)
10kA per line / 20kA total
Max. Continuous Operating Voltage
33 V /23.3 V

Mechanical

Terminal Size
0.08–4 mm² (solid), 0.08–2.5 mm² (flexible)

Dimensions & Physical Data

Depth
51mm
Height
45mm
Width
12mm

Environmental

Operating Temperature
-40°C to 80°C
IP Rating
IP20
