DEHN BXTML4BE12 Lightning Current Arrester 10kA 0.75A 12V 2.7MHz 12mm W 51mm D 45mm H Polyamide Yellow IP20

Product Code: BXTML4BE12

  • Protects signal lines with 12V, 0.75A capacity
  • Compact design: 12mm width, IP20 rating
  • Operates in extreme temps: -40 to 80°C
  • Complies with IEC/EN standards for safety
  • Compatible with Blitzductor XT system
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Combined Lightning Current And Surge Arrester Module
Brand
DEHN
Series
BLITZDUCTOR XT
Application
For protecting four single lines sharing a common reference potential as well as unbalanced interfaces

Electrical

Lightning Impulse Current Iimp (10/350µs)
10kA
No. of Lines/Pairs
4 single lines
Nominal Current (In)
750 mA
Nominal Voltage
12V
Voltage Protection Level Up
38V
Nominal Discharge Current Inom (8/20µs)
20kA
Max. Continuous Operating Voltage
10.6 V AC / 15 V DC

Environmental

Operating Temperature
-40°C to 80°C
IP Rating
IP20

Documents

IPD Product Catalogue V17
