DEHN BXTML4BD60 Lightning Current Arrester 10kA 1A 60V 11MHz 12mm W 51mm D 45mm H Polyamide Yellow IP20

Product Code: BXTML4BD60

  • Surge Protection Device for 60V systems
  • Compact size: 12mm width, 45mm height
  • Operates in -40 to 80°C range
  • Meets IEC, UL, ATEX standards
  • Compatible with Blitzductor XT
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Combined Lightning Current And Surge Arrester Module
Brand
DEHN
Series
BLITZDUCTOR XT
Application
For protecting two pairs of unearthed balanced interfaces

Electrical

Lightning Impulse Current Iimp (10/350µs)
10kA
No. of Lines/Pairs
2 pairs
Nominal Current (In)
1.0 A
Nominal Voltage
60V
Voltage Protection Level Up
90V
Nominal Discharge Current Inom (8/20µs)
20kA
Max. Continuous Operating Voltage
49.5 V AC / 70 V DC

Environmental

Operating Temperature
-40°C to 80°C
IP Rating
IP20

Documents

IPD Product Catalogue V17
