DEHN BXTML4B180 Lightning Current Arrester 10kA 1.2A 180V 12mm W 51mm D 45mm H Polyamide Yellow IP20

Product Code: BXTML4B180

  • Compact design: 12 mm width
  • High temp range: -40 to 80°C
  • Meets IEC & ATEX standards
  • Lightning impulse current: 10 kA
  • Compatible with Blitzductor XT
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Lightning Current Arrester Module
Brand
DEHN
Series
BLITZDUCTOR XT
Application
For protecting four single cores

Electrical

Lightning Impulse Current Iimp (10/350µs)
10kA
No. of Lines/Pairs
4 single lines
Nominal Current (In)
1.2 A
Nominal Voltage
180V
Voltage Protection Level Up
650V
Nominal Discharge Current Inom (8/20µs)
20kA
Max. Continuous Operating Voltage
127 V AC / 180 V DC

Environmental

Operating Temperature
-40°C to 80°C
IP Rating
IP20

Documents

IPD Product Catalogue V17
