DEHN BXTML2MY250 Lightning Current Arrester 0.6kA 3A 250V 20MHz 12mm W 51mm D 45mm H Polyamide Yellow IP20

Product Code: BXTML2MY250

  • Compact size: 12mm width, 45mm height
  • Wide temp range: -40 to 80°C
  • Compliant with IEC and EN standards
  • Suitable for Blitzductor XT systems
  • Durable polyamide construction
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Surge Arrester Module
Brand
DEHN
Series
BLITZDUCTOR XT
Application
For protecting two lines of stranded signal interfaces up to 250 V a.c.

Electrical

Lightning Impulse Current Iimp (10/350µs)
0.6kA
No. of Lines/Pairs
1 balanced interface
Nominal Current (In)
3.0 A
Nominal Voltage
250V
Voltage Protection Level Up
1100V
Nominal Discharge Current Inom (8/20µs)
5kA
Max. Continuous Operating Voltage
500 V AC / 620 V DC

Environmental

Operating Temperature
-40°C to 80°C
IP Rating
IP20

Documents

IPD Product Catalogue V17
