DEHN BXTML2BDSEX24 Lightning Current Arrester 4kA 1kA 0.5A 24V 6MHz 45mm H

Product Code: BXTML2BDSEX24

  • Surge protection for 24 V systems
  • Compact size: 12 mm wide, 45 mm high
  • Operates in -40 to 80°C range
  • Complies with IEC and ATEX standards
  • Suitable with Blitzductor XT
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Surge Arrester Module
Brand
DEHN
Series
BLITZDUCTOR XT
Application
For protecting one pair of intrinsically safe and galvanically isolated balanced interfaces, 4-20 mA, Profibus PA. Direct or indirect shield earthing

Electrical

Lightning Impulse Current Iimp (10/350µs)
4kA
No. of Lines/Pairs
1 pair
Nominal Voltage
24V
Voltage Protection Level Up
45V
Nominal Discharge Current Inom (8/20µs)
10kA
Max. Continuous Operating Voltage
23.3 V AC / 33 V DC

Environmental

Operating Temperature
-40°C to 80°C
IP Rating
IP20
